Garrett GT Series, Performance Turbochargers
Garrett GT2860R Series Ball Bearing Turbochargers
Garrett GT2860R Series Ball Bearing Turbochargers – dual ball bearing turbocharger supporting 150–360 hp suiting 1.8L–3.0L engines. Enquire with Procharge for sizing advice, pricing and availability.
Part No.
707160-0009, 707160-0005, 739548-0001
Power
Up to
360
HP
Engine Size
1.8L - 3.0L
Bearing
Dual Ball Bearing
Wastegate
Internal Wastegate
Suits
Pricing & availability on request
Tell us your vehicle and power goals – we’ll confirm fitment, options, pricing and lead time. We match or better any genuine advertised price.
Key features
Dual Ball Bearing
Oil & Water Cooled
2 Bolt Compressor Inlet
2 Bolt Compressor Outlet
Internally Wastegated
Inconel Turbine Wheel*
Ni-Resist Turbine Housing*
T25 Turbine Inlet Flange - Threaded
5 Bolt Turbine Outlet Flange
Actuator NOT Included
Specifications
| Part / model number | 707160-0009, 707160-0005, 739548-0001 |
|---|---|
| Power rating (from) | 150 HP |
| Power rating (up to) | 360 HP |
| Engine size | 1.8L - 3.0L |
| Bearing | Dual Ball Bearing |
| Cooling | Oil & Water Cooled |
| Wastegate | Internal Wastegate |
| Fuel | |
| Suits | |
| Compressor inducer | 44.5mm / 47.2mm |
| Compressor exducer | 59.4mm / 60mm |
| Compressor trim | 56 / 62 / 60 |
| Compressor A/R | 0.42 / 0.60 |
| Turbine wheel | 53.8mm |
| Turbine trim | 76 |
| Turbine A/R | 0.64 / 0.86 |
| Turbine flanges |
Product details & options
GT2859R Ball Bearing Turbocharger
Available options
| Model | Power | Engine size | Part no. | Comp. A/R | Turbine A/R |
|---|---|---|---|---|---|
| GT2859R-GTR | 150–310 HP | 1.8L – 3.0L | 707160-0009 / GT2859R | 0.42 | – |
| GT2860R-GTR | 250–360 HP | 1.8L – 3.0L | 707160-0005 / GT2860-GTR | 0.60 | 0.64 / 0.86 |
| GT2860RS | 250–360 HP | 1.8L – 3.0L | 739548-0001 / GT2860RS | 0.60 | – |
