Garrett GT5533R-GT6 Ball Bearing Turbocharger

Pricing & availability on request

Tell us your vehicle and power goals – we’ll confirm fitment, options, pricing and lead time. We match or better any genuine advertised price.

Enquire about this product (03) 8015 6103

Garrett GT Series, Performance Turbochargers

Garrett GT5533R-GT6 Ball Bearing Turbocharger

Garrett GT5533R-GT6 Ball Bearing Turbocharger – dual ball bearing turbocharger supporting 1000–1500 hp suiting 3.0L–12.0L engines. Enquire with Procharge for sizing advice, pricing and availability.

Part No. 769115

Power Up to 1500 HP

Engine Size 3.0L - 12.0L

Bearing Dual Ball Bearing

Wastegate

Suits

Pricing & availability on request

Tell us your vehicle and power goals – we’ll confirm fitment, options, pricing and lead time. We match or better any genuine advertised price.

Enquire about this product (03) 8015 6103

Key features

Dual Ball Bearing Oil Cooled .69 A/R Compressor Cover Ported Anti-Surge Shroud 6" Compressor Inlet 3.5" Compressor Outlet External Wastegate GT6 Undivided Turbine Inlet 5" V-Band Turbine Outlet

Specifications

Part / model number	769115
Power rating (from)	1000 HP
Power rating (up to)	1500 HP
Engine size	3.0L - 12.0L
Bearing	Dual Ball Bearing
Cooling
Wastegate
Fuel
Suits
Compressor inducer	91.2mm
Compressor exducer	133.0mm
Compressor trim	47
Compressor A/R	0.69
Turbine wheel
Turbine trim
Turbine A/R
Turbine flanges
