Garrett GTX Series, Performance Turbochargers
Garrett GTX4202R Ball Bearing Turbocharger
Garrett GTX4202R Ball Bearing Turbocharger – dual ball bearing turbocharger supporting 550–1150 hp suiting 2.0L–8.0L engines. Enquire with Procharge for sizing advice, pricing and availability.
Part No.
800269
Power
Up to
1150
HP
Engine Size
2.0L - 8.0L
Bearing
Dual Ball Bearing
Wastegate
Suits
Pricing & availability on request
Tell us your vehicle and power goals – we’ll confirm fitment, options, pricing and lead time. We match or better any genuine advertised price.
Key features
10%+ Overall Gain Over GT Series
Dual Ball Bearing
Oil & Water Cooled
5" Compressor Inlet
V-Band Compressor Outlet
11 Full-Blade Forged & Machined Billet C-Wheel
Optional Turbine Housings Available
External Wastegate
Specifications
| Part / model number | 800269 |
|---|---|
| Power rating (from) | 550 HP |
| Power rating (up to) | 1150 HP |
| Engine size | 2.0L - 8.0L |
| Bearing | Dual Ball Bearing |
| Cooling | Oil & Water Cooled |
| Wastegate | |
| Fuel | |
| Suits | |
| Compressor inducer | 75.8mm |
| Compressor exducer | 102.0mm |
| Compressor trim | 55 |
| Compressor A/R | 0.60 |
| Turbine wheel | 82.0mm |
| Turbine trim | 84.00 |
| Turbine A/R | |
| Turbine flanges |
Product details & options
GTX4202RBall Bearing Turbocharger
Garrett’s New Ultra Hi-Flow GTX Compressor Wheel
11 Full-Blade Forged & Machined Billet
Click Image for a Closer View ->
Optional Tial Turbine Housing
- Tial Dual V-Band Housing
- External Wastegate (EWG)
- Available in 1.01 A/R Only
- Stainless Steel – Lightweight
RELATED ITEMS
Oil Inlet
Gos-T34-01
- Gasket Oil Supply
- *Inc. with Turbo
Fos-T34-01
- CNC Billet Aluminium Oil Feed Flange
Oil Drain
God-T34-01
- Gasket Oil Drain
- *Inc. with Turbo
Fod-T34-01
- CNC Billet Aluminium Oil Drain Flange
- 1/2″ NPT Female Thresd
Air Oulet
FCO-005K
- 3.5″ Compressor Outlet Flange Kit
- Slip on 3.5″ Hose or Weld to Outlet Pipe
- Machined to Support an O-Ring
- Adaptor, O-Ring & V-Band Clamp Included in Kit
- Typically for GT42, GT42R, GT42RS Turbos
Water In-Out
FBK-M1805
- M18 Universal Water Kit
- M18 Banjo x 3/8 NPT-F (1)
- M18 x 1.50 Banjo Bolt (1)
- M18 Copper Washers (2)
- Suitable for Barb or Flare Nut Fitting
Exhaust Inlet
GT4D-01
- GT4 Stainless Steel Base Gasket
- *Inc. with Turbo
GT6D-01
- GT6 Stainless Steel Base Gasket
- *Inc. with Turbo
Exhaust Outlet
FVB-004M
- 4″ V-Band Weld Flange – Mild Steel
- CNC Machined From Solid Billet Stock
FVB-004S
- As Above – Stainless Steel
CVB-004
- 4″ V-Band Clamp
- Heavy Duty
- Stainless Steel
FVB-005M
- 5″ V-Band Weld Flange – Mild Steel
- CNC Machined From Solid Billet Stock
FVB-005S
- As Above – Stainless Steel
Awaiting Stock
CVB-005
- 5″ Heavy Duty Stainless Steel
Wastegates
T-V60-D
- Tial V60 60mm Wastegate Kit
- Default Colour – Silver
- Default Spring – .673 Bar – 9.77 PSI
- Click Here for More Options!
Applicable Garrett Part Numbers
800269-0002, 800269-2, 451888-0044, 451888-44
